| Product: | 26erx4.80 Carbon Fat Bike | Material: | Carbon Fiber |
|---|---|---|---|
| Max Tire: | 26erx 4.80 | Dropout: | 190x12 Mm |
| Bottom Bracket: | 120 Mm | Sizes: | 16", 18", 20" |
| Highlight: | road race bike frames,hardtail bike frame |
||
26er Full Carbon Lightweight Bike Frame 26erx4.80 Snow Fat Bike
Features:
1. 26er Lightweight Carbon Fat Bike Frame only 1290 grams for 18".
2. Rear Dropout 190 x 12 mm with Max tire 26erx4.80
3. BB GXP120 mm , Sizes 16", 18", 20" available
3. OEM/ODM orders are acceptable. customized painting designs
Technical Data:
| Product Name | 26er Lightweight Carbon Fat Bike Frame, Snow Bike Frame |
| Material | Full Carbon Fiber, Toray T700 |
| Model | CFM-248 |
| Wheel Size | 26er |
| Max Tire | 26erx4.80 |
| Dropout | 190x12 thru-axle |
| BB | GXP 120mm |
| Head tube | Tapered(44/56mm) |
| Seat post | 31.6mm |
| Front Derailleur | Pull Up |
| Head tube angle | 68.5° |
| Seat tube angle | 73.5° |
| Stack | 625 mm(20") |
| Reach | 437.4 mm(20") |
| RC | 445mm |
| Routing | Internal Cable Routing |
| Brake | Disc(Post Mount, Hidden) |
| Sizes | 16"(s), 18"(m), 20"(L) |
| Weight: | 1290±40g grams(18"), 520g±20g (Fork) |
| Bottle Cage Space | 2 |
| Accesories | 190x12 thru-axle included, fork is optional |
| Weave | 3K/12K/UD |
| Painting | Matte/Glossy, Cutomized paintings as per customers' requirement |
| OEM/ODM | Acceptable |
| Application | Fat bike, Snow bike, fatbike |
| Warranty | 2 years |
