26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout

China 26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout supplier
26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout supplier 26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout supplier 26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout supplier 26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout supplier

Large Image :  26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout

Product Details:

Place of Origin: CHINA
Brand Name: ORISUN
Certification: EN,ISO9001
Model Number: CFM-248

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton
Delivery Time: 20-25 days
Payment Terms: T/T, L/C At Sight
Supply Ability: 20000 units/month
Contact Now
Detailed Product Description
Product: 26erx4.80 Carbon Fat Mountain Bike Material: Carbon Fiber Toray T700 &T800
Maximum Tire: 26erx4.80 Dropout: 190x12 Mm Thru-axle
Bottom Bracket: 120 Mm Sizes Available: 16", 18", 20"
Weight: 1290g±40g (Frame),520g±20g (Fork) Warranty: 2 Years





26erx4.80 Lightweight Carbon Fat Bike Frame Fork Dropout 190mmx12 Snow Bike

Features:



1.  26"x4.80 Lightweight Carbon Fat Bike Frame only 1290±40g grams for 18".

2.  Rear Dropout 190 x 12 mm thru-axle, BB GXP120mm, with maximum tire 26"x4.80

3.  Sizes available 16", 18", 20".

4.  OEM/ODM orders are acceptable.

5.  2 years warranty


Technical Data:


Product  26erx4.80 Carbon Fat Mountain Bike Frame/Snow Bike Frame
Material Full Carbon Fiber, Toray T700/T800
Model CFM-248
Wheel Size 26er
Maximum Tire 26erx4.80
Rear Dropout 190x12 mm thru-axle
Bottom Bracket GXP 120mm
Head tube Tapered(44/56mm)
Seat post OD 31.6mm
Front Derailleur Pull Up
Head tube angle 68.5°
Seat tube angle 73.5°
Stack 605 mm(18")
Reach 423 mm(18")
RC 445mm
Routing Internal Cable Routing
Brake Disc(Post Mount, Hidden)
Sizes available All popular sizes available
Weight: 1290±40g grams(18"), 520g±20g (Fork)
Bottle Cage Space 2
Accesories 190x12 thru-axle included
Carbon Rigid Fork available
Weave 3K/12K/UD
OEM/ODM Acceptable
Painting Customized Painting/Logo acceptable
Warranty 2 years

26 Inch Snow Carbon Fat Bike Frame Lightweight 190 X 12 Mm Thru - Axle Dropout
